WG-38 Chinese Industry Platform Pipe Bender Price
- This product is customized, please consult customer service in detail before purchase, we will give you professional answers.
- Bending different tubes, and different specifications, all need different molds.
| Weight | 260 kg |
|---|---|
| Dimensions | 90 × 80 × 100 cm |
| Bending diameter range | 4-38mm |
| Bending Speed | 10-12r/min |
| Max Bending Angle | 180 |
| Min Bending Angle | 5 |
Details about WG-38 Chinese Industry Platform Pipe Bender Price
Adapt to various types of pipe bending, tell me the material, wall thickness, diameter (inner diameter), bending angle, or radian of the bending pipe, and we will recommend the most suitable pipe bender for you!
| Model | WG-26 | WG-38 | WG -51 | WG-76 |
| Bending diameter range | 4-26mm (thickness:2mm) |
4-38mm (thickness:3mm) |
4-51mm (thickness:3mm) |
4-76mm (thickness:3mm) |
| Bending Speed | 20r/min | 10-12r/min | 4-6r/min | 3-5r/min |
| Max Bending Angle | 180 | 180 | 180 | 180 |
| Min Bending Angle | 5 | 5 | 5 | 5 |
| Motor power | 2.2kw | 3kw | 3kw | 4kw |
| Power supply | 380V,50HZ,3P | 380V,50HZ,3P | 380V,50HZ,3P | 380V,50HZ,3P |
| Footswitch voltage | DC 5V | DC 5V | DC 5V | DC 5V |
| Overall dimension | 800*650*900 | 900*800*1000 | 950*850*1000 | 1000*900*1100 |
| Total weight | 180kg | 260kg | 320kg | 350kg |
| The mold needs to be customized 220VC be customized | ||||
The Platform pipe bending machine is applicable for bending stainless steel and other kinds of thin-wall metal pipes into arc shapes. It is suitable for round, square, and rectangular pipes and features smooth round bending.
